Electric Driven Fully Extendable Conveyor Belt For Bulk Materials Handling
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI |
| Certification: | mill certificate |
| Model Number: | extendable conveyor |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 10000-60000 |
| Packaging Details: | nude |
| Delivery Time: | 120 days |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 220 set/ year |
|
Detail Information |
|||
| Product: | Telescopic Conveyor Belt | Color: | Blue |
|---|---|---|---|
| Type: | Extendable | Painting: | INTERNATIONAL |
| Character: | Electric Driven | Length: | Advise By User |
| Width: | Advise By User | Benefit: | Low Cost |
| High Light: | Fully Extendable Conveyor Belt,Bulk Materials Handling Extendable Conveyor Belt,Industrial Conveyor Belt Electric Driven |
||
Product Description
Tailor made fully extendable conveyor belt for bulk materials handling
Shanghai Sunshine industry technology co., Ltd has been designing and supplying client bulk materials conveying systems for industries around the world since the past six years. Whether you are looking for a piece of equipment or a complete turnkey system, we are happy to offer you a customized solution, just customized to you specification requirement. We can provide bulk material handling system both new projects and existing systems. It`s used for handling comment material such as: coal, clinker, aggregates, biomass products grain gypsum, iron ore, limestone, sulfur.
specification of standard telescopic conveyor belt
|
Width (mm) |
Telescopic device | Telescopic stroke(mm) | Walking speed(M/s) | Walking time(s) | Driving device | notes | ||
| Electric vehicle | reducer | brake | ||||||
| B=1400 | 2 | 3450 | 0.0085 | 40.6 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 6200 | 0.085 | 73 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
| B=1200 | 2 | 3050 | 0.085 | 35.9 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 5700 | 0.085 | 67 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
| B=1000 | 2 | 2800 | 0.085 | 32.9 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 5450 | 0.085 | 64 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
Photos of our factory
