Customized Heavy Duty Apron Feeder For Opencast Mines Ore Conveying

Product Description

Customized heavy duty apron feeders for ore conveying at opencast mines

SSI reciprocating feeders are an idea for direct feeding processing machinery such as roller crusher, cone crusher, jaw crusher, impact crusher, and hammer crusher. The feeders can be also used to feed screens, roller sizers, and conveyor belts. All the feeds can be designed based on the specification of the client`s requirement.

A light-duty apron feeder is a continuous feeding machine, which is suitable for conveying block materials with feeding particle size below 160mm in a short distance. In mining, concentrator, chemical industry, cement, building materials, and other departments, it is widely used for uniform and continuous feeding from storage bins to crushing, transportation, and other machinery. It can be installed horizontally or obliquely, with a maximum upward inclination of 20 degrees. It is generally suitable for materials with a loose density of less than 1200kg / m3, block weight less than 140kg, and temperature below 350 ℃.

The medium-duty apron feeder is an intermittent feeding machine, which is suitable for conveying block materials with feeding particle size below 400mm in a short distance. In mining, concentrator, chemical industry, cement, building materials, and other departments, it is widely used for uniform intermittent feeding from storage bins to crushing, transportation, and other machinery. It can be installed horizontally or obliquely, with a maximum upward inclination of 20 degrees. It is generally suitable for materials with a loose density of less than 12400kg / m3, block weight less than 500kg, and temperature below 400 ℃.

A heavy-duty apron feeder is the auxiliary equipment of transportation machinery. It is used as a continuous and uniform feeding from the silo to the primary crusher in the crushing and grading workshop of large concentrator and cement, building materials, and other departments. It can also be used to transport materials with large particle sizes and specific gravity in a short distance. It can be installed horizontally or obliquely, with a maximum inclination of 12 degrees. To avoid the direct impact of materials on the feeder, the silo is required not to be empty.

The SSI heavy duty apron feeders are min

Technical specification

About us

Shanghai Sunshine Industrial Technology Co., Ltd. takes the development of precision manufacturing capability as its strategic goal, integrates design capability and manufacturing capability, designs professional equipment and systems for handling various dry bulk cargoes, and specializes in manufacturing large and medium-sized precision parts for the equipment. Shanghai Sunshine has excellent R & D and design ability of bulk cargoes conveying equipment and integrates the outstanding manufacturing capacity and years of rich manufacturing experience of Tonglu Fuchunjiang Power Generation factory. Shanghai Sunshine has strong technical ability and production ability with high quality and low labor price. Our load and unload equipment includes a train tipping machine, ship unloader, ship loader, etc. Our conveying equipment includes a belt conveyor, screw conveyor, chain bucket conveyor, scraper conveyor, inner bypass low-pressure dense phase pneumatic conveying system, etc. And our storage equipment includes bucket wheel stacker reclaimer, harrow reclaimer, scraper conveyor, etc. In addition, Shanghai Sunshine also provide parts and welding steel structure for heavy equipment.

Photos of our factory
