Heavy Duty Reciprocating Feeder For Direct Feeding Processing Machinery
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI |
| Certification: | mill certificate |
| Model Number: | SSI-300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | nude |
| Delivery Time: | 90 days |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 200 set/year |
|
Detail Information |
|||
| Product: | Paddle Feeder | Color: | Gray |
|---|---|---|---|
| Painting: | Jotun | Type: | Electric |
| Capacity: | 400t/h | Welding: | Inspected |
| Character: | High Performance | Advnatage: | Reliable |
| High Light: | Processing Machinery Reciprocating Plate Feeder,Heavy Duty Reciprocating Feeder,Direct Reciprocating Feeder |
||
Product Description
Tailor made heavy duty reciprocating feeder for direct feeding processing machinery
SSI reciprocating feeders are idea for direct feeding processing machinery such as roller crusher, cone crusher, jaw crusher, impact crusher and hammer crusher. The feeders can be also used to feed screens, roller sizers and conveyor belt. All the feeds can be designed based on the specification of client`s requirement.
Heavy duty reciprocating feeder is an auxiliary equipment of transportation machinery. It is used as a continuous and uniform feeding from the silo to the primary crusher in the crushing and grading workshop of large concentrator and cement, building materials and other departments. It can also be used to transport materials with large particle size and specific gravity in a short distance. It can be installed horizontally or obliquely, with a maximum inclination of 12 degrees. In order to avoid direct impact of materials on the feeder, the silo is required not to be empty.
The medium-duty apron feeder is an intermittent feeding machine, which is suitable for conveying block materials with feeding particle size below 400mm in a short distance. In mining, concentrator, chemical industry, cement, building materials and other departments, it is widely used for uniform intermittent feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely, with a maximum upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 12400kg / m3, block weight less than 500kg and temperature below 400 ℃.
Technical specification
| Model | A | B | C | H | H1 | H2 | H3 | L | L1 | L2 | L3 | L4 | S | S1 |
| K-0 | 1360 | 3100 | 846 | 210 | 416 | 325 | 1051 | 2450 | 840 | 1000 | 800 | 750 | 1040 | 750 |
| K-1 | 1360 | 3100 | 1112 | 210 | 416 | 325 | 1051 | 2450 | 840 | 1000 | 800 | 750 | 1040 | 1000 |
| K-2 | 1360 | 3540 | 1112 | 208 | 684 | 325 | 1297 | 2850 | 1150 | 1250 | 1050 | 1000 | 940 | 1000 |
| K-3 | 1352 | 3950 | 1360 | 250 | 640 | 345 | 1341 | 3270 | 1400 | 1500 | 1300 | 1250 | 1157 | 1250 |
| K-4 | 1622 | 4740 | 1632 | 330 | 762 | 345 | 1534 | 3850 | 1700 | 1750 | 1550 | 1500 | 1435 | 1500 |
About us
Shanghai Sunshine Industrial Technology Co., Ltd. takes the development of precision manufacturing capability as its strategic goal, integrates design capability and manufacturing capability, designs professional equipment and systems for handling various dry bulk cargoes, and specializes in manufacturing large and medium-sized precision parts for the equipment. Shanghai Sunshine has excellent R & D and design ability of bulk cargoes conveying equipment and integrates the outstanding manufacturing capacity and years of rich manufacturing experience of Tonglu Fuchunjiang Power Generation factory. Shanghai Sunshine has strong technical ability and production ability with high quality and low labor price. Our load and unload equipment including train tipping machine, ship unloader, ship loader, etc. Our conveying equipment including belt conveyor, screw conveyor, chain bucket conveyor, scraper conveyor, inner bypass low-pressure dense phase pneumatic conveying system, etc. And our storage equipment including bucket wheel stacker reclaimer, harrow reclaimer, scraper conveyor, etc. In addition Shanghai Sunshine also provide parts and welding steel structure for heavy equipment.
To be sincere and keep moving! Shanghai Sunshine Industrial Technology Co., Ltd. always dedicate to high quality products and service!
Photos of our factory
