Heavy Duty Telescopic Conveyor Belt System For Bulk Material Handling
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI |
| Certification: | mill certificate |
| Model Number: | customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 10000-60000 |
| Packaging Details: | nude |
| Delivery Time: | 120 days |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 220 set/ year |
|
Detail Information |
|||
| Description: | Telescopic Conveyor Belt | Color: | Grey |
|---|---|---|---|
| Type: | Telescopic | Painting: | Jotun |
| Character: | Reliable | Length: | Advise By User |
| Width: | Customized | Benefit: | Low Cost |
| High Light: | Heavy Duty Belt Conveyor Telescopic,Bulk Material Handling Extendable Conveyor Belt,Heavy Duty Telescopic Conveyor System |
||
Product Description
Customized heavy duty telescopic conveyor belt for bulk material handling telescopic head belt conveyor
Shanghai Sunshine industry technology co., Ltd has been designing and supplying client bulk materials conveying systems for industries around the world for the past six years. Whether you are looking for a piece of equipment or a complete turnkey system, we are happy to offer you a customized solution, just customized to your specification requirement. We can provide bulk material handling systems for both new projects and existing systems. It`s used for handling comment material such as coal, clinker, aggregates, biomass products grain gypsum, iron ore, limestone, sulfur.
The telescopic belt conveyor can expand freely in the length direction and control the length of the conveyor at any time. It can transport materials in two directions and can be used together with other conveying equipment and material sorting system to realize the automatic production of material in and out of warehouse or vehicle loading and unloading. It has been widely used in various industries
automatic production of material in and out of warehouse or vehicle loading and unloading. It has been widely used in various industries
The use of telescopic belt conveyor shortens the distance of manual round-trip handling of materials, shortens the time of cargo loading and unloading, reduces labor intensity, reduces cargo damage, reduces loading and unloading costs, and improves work efficiency. Telescopic belt conveyor was first used in logistics express and tobacco industry.
specification of standard telescopic conveyor belt
|
Width (mm) |
Telescopic device | Telescopic stroke(mm) | Walking speed(M/s) | Walking time(s) | Driving device | notes | ||
| Electric vehicle | reducer | brake | ||||||
| B=1400 | 2 | 3450 | 0.0085 | 40.6 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 6200 | 0.085 | 73 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
| B=1200 | 2 | 3050 | 0.085 | 35.9 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 5700 | 0.085 | 67 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
| B=1000 | 2 | 2800 | 0.085 | 32.9 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
High support structure |
| 3 | 5450 | 0.085 | 64 |
Y112M4 4KW 1440/min |
XWE4-95 I=187 |
TJ2-200 1.6dan-m |
Floor type structure | |
