Longitudinal Stockyard Scraper Type Reclaiming System For Coal Handling
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI-ZHIGO |
| Certification: | manufacture certificate |
| Model Number: | Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | US $500,000-1,000,000/ Set |
| Packaging Details: | Wooden case or bare |
| Delivery Time: | 6 months after receipt of advance payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 40 sets / year |
|
Detail Information |
|||
| Item: | Scraper Type Reclaimer | Capacity: | 1000 T/h |
|---|---|---|---|
| Painting: | Jotun | Color: | Blue |
| Character: | Scraper Type | Electric Component: | European Brand |
| Steel Work: | Welding | Welding: | GMAW |
| High Light: | Longitudinal Stockyard Scraper Reclaimer,Coal Handling Scraper Reclaimer |
||
Product Description
Longitudinal stockyard scraper type reclaiming system for coal handling
The gantry scraper reclaimer is mainly used for scraping sandstone, ore, sandstone, coke, and other bulk materials in the stockyard of large enterprises such as water conservancy companies, steel companies, coal coking companies, and cement companies. It`s suitable for stacking material piles flexibly and not strictly informing material piles in longitudinal stockyards.
The gantry scraper reclaimer is mainly composed of a traveling mechanism, gantry, scraper conveying system, luffing system, electrical control room, etc
Specification of gantry scraper reclaimer
| description | parameter | unit |
| material | Coal, ore, etc | |
| density | 0.8~2.3 | t/m3 |
| granularity | <70 | mm |
| moisture | <2 | % |
| reclaiming capacity | 200~2000 | t/h |
| rail span | 20~50 | m |
NOTICES
The customer shall provide the following information when placing order
- the character of bulk material
- Stockyard information
- Process flow chart
- Power supply
- Communication and control requirements
About us
Shanghai Sunshine Industrial Technology Co., Ltd. takes the development of precision manufacturing capability as its strategic goal, integrates design capability and manufacturing capability, designs professional equipment and systems for handling various dry bulk cargoes, and specializes in manufacturing large and medium-sized precision parts for the equipment. Shanghai Sunshine has excellent R & D and design ability of bulk cargoes conveying equipment and integrates the outstanding manufacturing capacity and years of rich manufacturing experience of Tonglu Fuchunjiang Power Generation factory. Shanghai Sunshine has strong technical ability and production ability with high quality and low labor price. Our load and unload equipment includes a train tipping machine, ship unloader, ship loader, etc. Our conveying equipment includes a belt conveyor, screw conveyor, chain bucket conveyor, scraper conveyor, inner bypass low-pressure dense phase pneumatic conveying system, etc. And our storage equipment includes bucket wheel stacker reclaimer, harrow reclaimer, scraper conveyor, etc. In addition, Shanghai Sunshine also provide parts and welding steel structure for heavy equipment.
