Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel

Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel

Product Details:

Place of Origin: China
Brand Name: SSI
Certification: ABS/BV/CCS/GL/RINA/RMRS/LR
Model Number: 2t20m

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 200000
Packaging Details: nude
Delivery Time: 3.5 months
Supply Ability: 30set/year
Get Best Price Contact Now

Detail Information

Product: Foldable Boom Marine Crane Color: Advise By User
Painting: According To ISO12944 Character: Electric Hydraulic
Type: Foldable And Telescopic Boom Model: SSI-2t20m
Advantage: High Performance Benefit: Low Cost
High Light:

Foldable boom Marine Cranes

,

Knuckle Boom Marine Cranes

,

Electric Hydraulic Pedestal Jib Crane

Product Description

Electric hydraulic foldable boom marine crane installed on multi purpose vessel



The foldable boom marine crane, offshore crane is designed as an electro-hydraulic driven articulated boom crane, with integrated electro-hydraulic power package or independent electro-hydraulic power package, delivered as a complete unit ready for installation to foundation. The crane is equipped with hydraulic powered winch, hydraulic powered luffing, hydraulic powered extension and hydraulic powered slewing system.

The crane is installed with a rolled steel pedestal for bolting or welding to deck foundation with a standard height of the crane. The different pedestal height is available base on customer`s requirement. The standard foldable boom crane is supplied with an operator seat mounted on crane house. Operator control station is available base on customer`s requirement.



Technical specification



1 SWL 2t@20m
2 Max working radius 20m
3 Min working radius 3m
4 Hosting speed 0~12m/min
5 Slewing speed 1r/min
6 Slewing angle 360° free
7 Luffing time 60s
8 Hook travel 30m
9 Folding time 65s
10 Extension time 120s
11 Working condition
  Heel ≤ 5°
  Trim ≤ 2°
12 Electric motor
  Power 37 Kw
  Speed 1480r/min
  Power source 440V 50Hz,
  Protect class F
  Working type S1
13 Flow 80L/min
14 Design temperature -10°~40°
15 Dead weight ~15500 kg



General drawing



Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel 0



Photos of our factory



Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel 1

Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel 2

Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel 3

Electric Hydraulic Foldable Boom Marine Crane Installed On Multi Purpose Vessel 4
