Product Details:

Place of Origin: china
Brand Name: SSI-CHEC
Certification: manufacture certificate
Model Number: customized

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US $1,500,000-5,000,000/ Set
Packaging Details: Wooden case or bare
Delivery Time: 6 months after receipt of advance payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 20 sets / year
Get Best Price Contact Now

Detail Information

Product: Ship Loader Painting: Jotun
Color: Orange Capacity: 5000 T/h
Character: Rail Mounted Advantage: High Performance
Benefit: Low Cost Motor: ABB
High Light:

Bulk Material Ship Loading Equipment

,

Ship Loaders With Telescopic Chute

,

Rail Mounted Ship Loader Conveyor

Product Description

Ship Loaders for Bulk Material Handling Ship Loader with

telescopic chute Ship Loaders with Gravity Spiral Chute



Ship loader is a large-scale bulk machinery used in bulk terminal loading. The general Ship loader is composed of boom belt conveyor, transition belt conveyor, telescopic chute, tail car, traveling device, gantry, tower, pitching mechanism, slewing mechanism, etc. Large port bulk loading equipment plays an important role in the high-speed, stable, efficient and rolling development of energy, power, metallurgy, port and other industries, especially some bulk material distribution centers. Ship loade is usually a continuous unloading operation. Therefore, there must be matching equipment to provide continuous material flow, so that the ship loader can ship continuously. Such as the granary feeding of grain terminal, the continuous feeding of bucket wheel reclaimer in the yard of coal terminal, etc.



Specification of ship loader



vessel capacity unload time lift capacity
of grab
weight of
single grab
cycle
times
one cycle density of
bulk material
rail
distance
rail wheel
pressure
extending reach distance
of grab
rear reach
distance of grab
hoisting
speed
lowering
speed
trolley
speed
traveling
speed
DWT t/h hours T T   s t/m3 m   kN m m m/min m/min m/min m/min
1000 340 2.94 10 5.5 61.82 58.23529 0.85 16 QU80 350 23 21 90 100 120 25
5000 500-2000 2.5~10 12.5~48 7.3~28 67.42~71.43 52.56-53.4 0.8~0.9 10.5~20 QU80~100 245~600 24~28 8~16 100~160 120~190 150~240 20
8000 1000 8.00 25 14.8 67.57 53.28   20 QU100 350 28 17 135 150 180 20
20000 800-1000 20.00 22~30 13.3~14.8 55.56~67.57 53.28~64.8 0.85 16~22 QU80~120 330~530 24~38 21 12~135 135~150 180 20~25
30000 1250 24.00 32 19.6 63.78 56.448 0.95 16 QU100 505 33 14 135 150 220 25
35000 800~1600 21.88~43.75 22~40.5 12.8~25 62.52~76.19 54~57.6 0.85~0.95 14~24 QU80~100 330~530 27~31 11~19 120~135 135~180 180~220 20~25
50000 1250~1650 33.3~40 32~40 19.5~25 60~67.35 56.16~60 0.85~0.95 22~26 QU100~120 500~520 30~33 17~19 150~200 180~240 180~220 20~25
70000 1250~1750 40~56 34~42 20.5~25.75 52.08~68 53~69.12 0.85~0.9 22~30 QU100~120 500~600 32~40 16.5~27 160~220 190~240 180~240 20~25
100000 1000~1800 55.56~100 30~46 18~27.6 55.56~75.12 48~64.8 0.8-1 22~26 QU120 450~600 30~38 17~20 135~180 150~220 180~240 25
150000 1800~2100 71.42~83.33 45~52 27.2~31.5 63.16~66.67 54~57 0.90~2.4 24~28 QU120 600~736 39~41.5 19~24 160~200 190~240 200~240 20~25



case 1

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 0

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 1



case 2



Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 2

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 3



case 3

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 4

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 5



case 4

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 6

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 7



case 5

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 8

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 9



case 6

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 10

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 11



case 7

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 12

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 13



case 8

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 14

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 15



case 9

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 16

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 17



case 10

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 18

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 19



case11

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 20

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 21



case12
Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 22

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 23


Photos of our factory

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 24

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 25

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 26

Rail Mounted Ship Loaders With Telescopic Chute For Bulk Material Handling 27
