Gantry Type Combined Bucket Wheel Stacker Reclaimer For Stockyard
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI-HDCZ |
| Certification: | manufacture certificate |
| Model Number: | Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | US $500,000-5,000,000/ Set |
| Packaging Details: | Wooden case or bare |
| Delivery Time: | 6 months after receipt of advance payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 40 sets / year |
|
Detail Information |
|||
| Item: | Stacker And Reclaimer | Painting: | 180um |
|---|---|---|---|
| Color: | Red | Capacity: | 1000 T/h |
| Character: | Heavy Duty | Advantage: | Low Maintenance |
| Benefit: | Durable | Material Handling: | Coal |
| High Light: | Bucket Wheel Stacker Reclaimer Gantry Type,Combined Bucket Wheel Stacker Reclaimer,Portal Stacker Reclaimer Stockyard |
||
Product Description
Gantry type combined bucket wheel stacker and reclaimer for stockyard stacking and reclaiming
Applications
Gantry type combined bucket wheel stacker and reclaimer can operate as stacker or as reclaimer. Gantry type combined bucket wheel stacker and reclaimer is mainly applied for coal power plants, industrial and mining enterprises and port bulk material stockyards.
feature
The gantry bucket wheel stacker and reclaimer was design as compact, high efficiency, automation and environmental friendly. The working area of the bucket wheel stacker and reclaimer is flexible, and the bulk material stacking and reclaiming operation can be carried out on different material pile.
composition
The gantry bucket wheel stacker and reclaimer is mainly composed of traveling mechanism, stacker belt conveyor, reclaimer belt conveyor, mobile belt conveyor, movable beam, lifting mechanism, tail stacker transfer mechanism, tail car, traveling device, steel structure, water spray system, lubrication system, electrical room, etc
specification of gantry bucket wheel stacker and reclaimer
| description | parameter | unit |
| bulk material | coal,coke,ore | |
| density | 0.6~2.2 | t/m3 |
| granularity | <300 | mm |
| moisture | <2 | % |
| stacking capacity | 200~3000 | t/h |
| reclaiming Capacity | 100~2000 | t/h |
| rail span | 20~60 | m |
NOTICES
The customer shall provide the following information when place order
- character of bulk material;
- Stockyard information;
- Process flow chart;
- Power supply;
- Communication and control requirements.
Photos of our factory
